630791 DS MKII INSTALLATION MANUAL
D4 Gas Supply
Escea does not condone using a 9kg bole as the main gas supply for an Escea re. Doing so could result in a
dirty or poor ame and produce excess soot build up.
D5 Gas Pipe Sizing
Gas pipe should be sized as per the requirements of AS/NZS 5601. The pipe sizing must be sucient to deliver
the following volume of gas to the heater with all other gas appliances in the home running at the same me:



D6 
The gas connecon is inside the appliance and is ½” male BSPT on the lower right of the appliance as shown
below. Access is through the silicone grommet circled below on the RH side of the chassis.
Gas Connection Point
Access for connecng the gas supply to the gas connecon point (shown in the diagram above) should be
through the access hatches located on the front and back of the appliance (the front as shaded in the diagram
below).
A
B
C
D
E
F
G
