630791 DS MKII INSTALLATION MANUAL
A PRODUCT DESCRIPTION AND DIMENSIONS
A1 
The Escea DS-Series gas re is a room sealed gas appliance designed to be built into a false cavity. It is a
powerful gas heater that, on the lowest seng (eect only) will sll generate approximately 50% heat. The
appliance is ued using co-linear exible aluminium ue. The user will control their re with the bluetooth
remote that will normally be located in its wall mount cradle. In addion to the remote the appliance has a
single auxiliary On/O buon on the unit. When not in operaon it is in a standby mode unless it is physically
isolated from the mains supply.
A2 
The following diagram illustrates the steps required to install your gas re. The sequence in which you choose
to do these tasks will vary depending on your individual scenario. Please read these instrucons fully before
proceeding with the installaon.
FALSE CAVITY INSTALLATION
CREATE THE CAVITY
INSTALL ELECTRICAL / GAS CONNECTIONS,
FLUE SYSTEM, AND FIREPLACE
FINISH INSTALLATION AND
FIT FASCIA
Secon B Secon C, D Secon F
A3 
NOT TO BE MISTAKEN FOR CAVITY DIMENSIONS
All dimensions are in mm.
A
B
C
D
E
F
G
