630791 DS MKII INSTALLATION MANUAL
E INSTALLING THE APPLIANCE
WARNING!
THE FOLLOWING INSTRUCTIONS MUST ONLY BE UNDERTAKEN BY A SUITABLY APPROVED PERSON. ANY
TAMPERING BY AN UNAUTHORISED PERSON WILL VOID THE PRODUCT’S WARRANTY AND MAY RESULT IN A
DANGEROUS CONDITION.
E1 
Access the top of the appliance and connect both the inlet ue (75 mm ID / 85 mm
OD) and the exhaust ue (100 mm ID / 110 mm OD) to their respecve spigots.
Tighten the hose clamps onto the spigots. Ensure the ue connecon is air ght.
Sealant is not required.



E2 
Insert the gas re into the cavity and x the appliance down in correct posion using the brackets on each end
of the appliance. It is a requirement that this appliance be securely fastened at the base.
WARNING!
ENSURE THAT THE FIRE IS SEISMICALLY RESTRAINED IN A MANNER APPROPRIATE TO THE INSTALLATION
LOCATION
E3 
Remove the glass by unscrewing the four 1/4 turn fasteners located at the top of the glass (circled below) and
remove the bracket (shaded grey). Allow the glass to lean towards you and carefully li it out.
Place the glass carefully aside. Note that any soot on the glass can mark carpet and furnishings.



WARNING!
TRYING TO PLACE THE GLASS WITH DEBRIS IN THE GLASS CHANNEL MAY RESULT IN THE GLASS BREAKING.
