Toggling to the low seng is done by pressing the “Low” buon. Adjustments are made with the ‘ ’ and ‘ ’
buons as above.
NOTE: When seng low, allow a tolerance of ±0.05 kPa
When pressures are set, exit this mode.
NOTE: This is a powerful gas heater that, on the lowest seng (eect only), will sll generate
approximately 50% heat.

E6 Gas Type Conversion
This appliance can be congured to operate on NG, ULPG, or Propane. If gas type conversion is required, please
contact an Escea dealer to request the required parts.
Gas Specic Conguraons
DS1150
Jets Burner Collars
Middle Burner Side Burners Pilot Middle Burner Side Burners
Natural Gas
1.95 mm 1.50 mm #37 1 x 3.5 mm Fully Closed
ULPG
1.30 mm 0.85 mm #27 Spacer 2 x 7 mm
Propane
1.30 mm 0.85 mm #27 2 x 12 mm 2 x 4 mm
DS1400
Jets Burner Collars
Middle Burner Side Burners Pilot Middle Burner Side Burners
Natural Gas
1.95 mm 1.70 mm #37 1 x 6 mm 1 x 3.5 mm
ULPG
1.25 mm 1.02 mm #27 Spacer 2 x 8 mm
Propane
1.30 mm 1.02 mm #27 2 x 13 mm 2 x 7 mm
DS1650
Jets Burner Collars
Middle Burner Side Burners Pilot Middle Burner Side Burners
Natural Gas with Crystalite
or Coals
1.95 mm 1.95 mm #37 Fully Closed Fully Closed
Natural Gas with All Logs
1.95 mm 1.95 mm #37 1 x 3.5 mm 1 x 3.5 mm
ULPG
1.20 mm 1.10 mm #27 Spacer 2 x 7 mm
Propane
1.20 mm 1.10 mm #27 2 x 12 mm 2 x 4 mm
