Essilor Pro-E 700 edger User Manual

Press to receive more image information about the tool assembly/dismantling procedure.
Press to cancel the action.
Position the blocking key on the back axle of the chamfering wheel.
Insert the Allen key into the screw at the center of the wheel and unscrew (towards yourself) the wheel,
using the Allen key.
Remove the screw and the chamfering wheel.
Be careful to save the screw.
Replace the old wheel with a new one.
2
3
4
5
Pro-E 600_Pro-E 700 > v1 -10.18
166
USER MANUAL> V. MAINTENANCE & SERVICING
