Essilor Pro-E 700 edger - Page 170

Remove the chamfering wheel and the spacer.
Position the “step ++” wheel on the axis.
Tighten (towards yourself) the “step ++” wheel using the torque wrench.
Ensure that the tool is correctly fixed onto the axle using the keys.
Remove the mounting tool and the Allen key
6
7
8
9
Pro-E 600_Pro-E 700 > v1 -10.18
170
USER MANUAL> V. MAINTENANCE & SERVICING
