2.2 AxiDraw anatomy
Let us look at the dierent parts of the AxiDraw. We will refer to these parts
by name throughout this guide. These features are common to each model of
AxiDraw, though appearances may vary slightly. For example, the AxiDraw V3/
A3 and SE/A3 have extended “outrigger” feet, and the AxiDraw SE/A3 base is
colored black and covers the two motors.
Pen holder
Base; Central strut
Base; Central strut
Left motor & cover
Right motor
& cover
Cable Guides
(Not handles!)
Carriage (X-axis part)
Pen holder
Top View
Carriage (Y-axis part)
Timing (drive) belt
