13
Instruction of protective cover (shield) of big belt wheel:
No.
Item
Application
When to dismantle
1
Auxiliary inner shield
To prevent hands injury of person
Do not dismantle
2
Inner shield
To prevent hands/hair/clothes from
pulling in
Do not dismantle
3
Fixing screw of inner shield
To fix the inner shield
Do not dismantle
4
Support screw of main
shield
To support and guide the main
shield
Do not dismantle
5
Fixing screw of main
To support and guide the main
shield
Do not dismantle
6
Main shield
To prevent hands/hair/clothes from
pulling in
When shifting the sawing
speed
7
Washer
To fix the bolt and nut of main shield
When shifting the sawing
speed
8
Fixing bolt of main shield
To fix the main shield securely
When shifting the sawing
speed
