Excel KP-200 - Tilt under Proper Pressure; Oil Level of Pressure Adjusting Value Decreases Abnormally

59
12-4. Tilt under Proper Pressure
ITEM 4 a
Malfunction
Tilt under proper pressure
Cause
a. Wear/tear of blade, incorrect teeth
Trouble shooting
a. Replace damaged blade with proper teeth
Remark
Refer to manual instruction to replace the parts
ITEM 4 b
Malfunction
Tilt under proper pressure
Cause
b. Insufficient blade tension
Trouble shooting
b. Use tension meter to adjust to proper tension
Remark
Refer to manual instruction to adjust proper tension
12-5. Oil Level of Pressure Adjusting Value Decreases Abnormally
ITEM 5 a
Malfunction
Oil level of pressure adjusting value decreases abnormally
Cause
a. Leaking of oil hose or connector
Trouble shooting
a. Replace the pipe or connector if damaged
Remark
a. Refer to manual to repair, or contact dealer/producer to supply parts
ITEM 5 b
Malfunction
Oil level of pressure adjusting value decreases abnormally
Cause
b. Damaged or deteriorated O ring or in the valve
Trouble shooting
b. Replace O ring, type :P-12 or P-22A
Remark
b. Replenish hydraulic oil, type: MOBIL DTE Light 32#
ITEM 5 c
Malfunction
Oil level of pressure adjusting value decreases abnormally
Cause
c. Damaged or deteriorated O ring on the top or bottom of cylinder
Trouble shooting
c. Check the O rings on top or bottom covers, replace the ring, type:
(KP-200) G105, ensure the O ring placed into the trough without
outstanding part
Remark
c. Refer to drawing 5 d to replace the part
