Chapter 2. Structure and Appearance of Machine
2-1. Performance and Function
2-1-1. Specification
MODEL
UNIT
KP-200
CUTTING CAPACITY ●
mm
200
CUTTING CAPACITY ▀(H*W)
mm
190*190
MAX. CUTTING DEGREE/DIA.
N。/mm
45。/90
DISTANCE OF STROKE
mm
120
STROKES PER. MIN.
times
105 . 125
BLADE SIZE
mm
350*32*1.6*8.3
MAIN MOTOR
HP(KW)
1 (0.75)
MEASUREMENT (L*W*H)
mm
1240*730*1010
NET WEIGHT
kg
270
GROSS WEIGHT
kg
330
Particular tools list
Name
Quantity
Name
Quantity
Grease gun 100G
1
4mm “L” Hexagon head
1
17mm*19mm Open end wrench
1
5mm “L” Hexagon head
1
6*100mm “+” Screw driver
1
6mm “L” Hexagon head
1
300mm Adjustable wrench
1
8mm “L” Hexagon head
1
11mm*13mm Open end wrench
1
Measure bar
1
Handle
1
Pressure bar
1
M16*2.0*45 Head cap screw
4
Balance bar
1
M14*2.0*70 Head cap screw
2
Material rack
1
Ø 14 Washer
2
Tool box
1
