Excel KP-200 - Page 78

72
Model: KP-200 Title: MACHINE BODY ASSEMBLY Drawing No: M-092001
ITEM
PART NO.
DESCRIPTION
SPECIFICATION
Q’TY
1
N-10-04
NUT
M6*1.0
4
2
P-25137
PULLEY SIDE COVER
1
3
N-10-02
NUT
M4*0.5
4
4
P-25119
MICRO SWITCH HOLDER
2
5
LM-18-02
MICRO SWITCH
TM1703
1
6
W-20-04
WASHER
Ø 6*12*0.6
9
7
S-04-03
HEX HEAD CAP SCREW
M6*1.0*12
4
8
S-02-02
“+” ROUND HEAD SCREW
M4*0.5*30
4
9
P-20121
PULLEY COVER
1
10
W-20-06
WASHER
Ø 10.5*Ø 25*1.5
1
11
UN-50-02
HANDLE
M10*1.5*25*50
1
12
P-25120-1
PULLEY COVER STRUT SCREW
1
13
P-25120-2
PULLEY COVER STRUT SCREW
1
14
N-10-06
NUT
M10*1.5
5
15
HE-20-01
PVC UNION
3/8”
4
16
EH-19-01
HOSE
3/8”
2
17
N-10-05
NUT
M8*1.25
8
18
SW-30-05
SPRING WASHER
Ø 8.5
8
19
S-05-08
SOCKET SET SCREW
M8*1.25*12
1
20
P-20227
MOTOR PULLEY
1
21
V-20-09
V-BELT
A-43
1
22
KY-15-06
KEY
8*8*35
1
23
MT-10-04
MOTOR
1HP-3PH-50HZ
1
24
P-25123
MOTOR PLATE
1
25
S-06-03
HEX SOCKET CAP SCREW
M10*1.5*40
1
26
GR-25-01
HANGER
5/8”
1
27
HW-14-01
COOLANT PIPE
1/4”PT*460
1
28
LM-18-01
MICRO SWITCH
TZ-7310
1
29
WH-30-01
PIPE
Ø 14*18*315
1
30
S-05-04
HEX HEAD CAP SCREW
M8*1.25*25
4
31
W-20-05
WASHER
Ø 8.5*20*1.5
4
32
P-11-04
TWO-HEAD PIPE
1/4”PT*1/4”PT*70
1
33
HW-14-02
VALVE
1/4”PT*1/4”PT
1
34
P-25126
ELECTRIC BOX
1
35
S-04-04
HEX SOCKET CAP SCREW
M6*1.0*20
6
36
WM-28-01
COOLANT PUMP
1/8HP
1
37
P-11-02
JOINT
3/8”PT*Ø14
2
38
HD-80-02
HANDLE
SK-63-8
2
39
P-20133-1
COVER
1
