Excel KP-200 - Page 81

75
Model: KP-200 Title: VISE ASSEMBLY Drawing No.: M-092002
ITEM
PART NO.
DESCRIPTION
SPECIFICATION
Q’TY
1
P-25130-2
TURN HANDLE
1
2
P-25130-1
TURN HANDLE SCREW
1
3
S-08-01
HEX HEAD CAP SCREW
M14*2.0*70
2
4
W-20-08
WASHER
Ø 14.5
2
5
P-25127
PIN
2
6
S-07-01
HEX SOCKET CAP SCREW
M12*1.75*45
1
7
P-25135
WASHER
Ø 12.5*Ø 32*5
1
8
S-07-02
HEX HEAD CAP SCREW
M12*1.75*50
1
9
P-20103
JAW (REAR)
1
10
P-25112
FIXED PLATE
1
11
P-20104
SCREW ROD
2
12
S-04-14
“+” ROUND HEAD SCREW
M6*1.0*10
2
13
P-20129
FIXTURE
1
14
P-20131
PUSH-RING
1
15
S-04-09
HEX HEAD CAP SCREW
M6*1.0*12
1
16
N-10-04
NUT
M6*1.0
1
17
N-11-03
NUT
3/4”-16UNC
4
18
P-25110
WASHER
3
19
P-20102
JAW (FRONT)
1
20
P-20132
EQUILIBRIUM ROD
1
21
P-20119
EQUILIBRIUM ROD PIN
1
22
S-04-03
HEX SOCKET CAP SCREW
M6*1.0*12
2
23
S-04-05
HEX SOCKET CAP SCREW
M6*1.0*25
1
24
P-25109
SCREW ROD FLANGE
1
25
S-04-04
HEX SOCKET CAP SCREW
M6*1.0*20
3
26
P-20107
VISE SCREW
1
27
P-25108
HANDLE
1
28
P-20111
SCREW ROD PROTECTOR COVER
1
29
P-25105
SLIDE BLOCK (FRONT)
1
30
P-25106
SLIDE BLOCK (REAR)
1
31
N-10-11
NUT
M20*2.5
1
