Excel KP-200 - Page 86

80
Model: KP-200 Title: CYCLINDER ASSEMBLY Drawing No.: M-092004
ITEM
PART NO.
DESCRIPTION
SPECIFICATIO
Q’TY
1
P-20327
SMALL PISTON TOUCH SHAFT
1
2
S-0404
HEX SOCKET CAP SCREW
M6*1.0*20
3
3
S-10-01
HEX SOCKET CAP SCREW
M6*1.0*10
3
4
P-20312
SLEEVE
1
5
P-20311
SPRING
1
6
S-04-05
HEX SOCKET CAP SCREW
M6*1.0*25
10
7
P-20303
TOP CAP
1
8
SO-35-05
O-RING
P-28
1
9
SO-35-09
O-RING
G-105
2
10
SE-32-01
OIL SEAL
UPH-28*43*10
1
11
RT-34-01
C-SNAP RING
RTW-43
1
12
P-25309
NUT
1
13
TA-33-03
BIG PISTON RING
100*3.0*3.5
2
14
SO-35-06
O-RING
P-90
1
15
P-20304
BIG PISTON
1
16
P-20305
BIG PISTON ROD
1
17
SO-35-03
O-RING
P-15
2
18
SE-32-02
OIL SEAL
UPH-15*25*8
1
19
RT-34-02
C-SNAP RING
RTW-25
1
20
TA-33-06
PISTON RING
F.S.Ø 51*2.5*2.2
2
21
P-20306
SMALL PISTON
1
22
P-20307
SPRING
1
23
P-20308
PISTON COVER
1
24
P-12-15
“L” SQUARE ELBOW
3/8”PT*3/8”HT
1
25
IK-26-02
DUST SEAL
RYD-28*35*5/6
1
26
P-20310
SPRING
3
27
SB-50-02
STEEL BALL
Ø7/16”
3
28
KT-20-01
PIN
Ø 3*23
2
29
S-04-03
HEX SOCKET CAP SCREW
M6*1.0*16
6
30
P-25314
BEARING COVER
2
31
BR-29-21
BALL BEARING
6006ZZ
2
32
P-20301
CYLINDER
1
33
P-12-11
“L” SQUARE ELBOW
1/4”PT*3/8”HT
1
34
P-12-04
CORK HOLDER
1/4” PT
1
35
P-20302
BOTTOM CAP
1
36
S-04-07
HEX SOCKET CAP SCREW
M6*1.0*55
4
37
SO-35-01
O-RING
P-9
3
38
AD-21-01
VALVE BODY
AD-8C
1
39
S-04-06
HEX SOCKET CAP SCREW
M6*1.0*30
2
