EXCELL PRECISION CO., LTD.
3-3-1 Baud Rate Settings
Select in the RS-232 Bi-directional settings mode
to set the Baud Rate.
C key  clear parameter
Enter key  perform action
LCD displays the last setting.
 Factory default value: 04
Parameter settings:
00  600 (bits/s)
01  1 200 (bits/s)
02  2 400 (bits/s)
03  4 800 (bits/s)
04  9 600 (bits/s)
05  19 200 (bits/s)
06  38 400 (bits/s)
Press Enter key
Press Enter key
To exit the RS-232
Bi-directional settings,
key in “00” and press
Enter key.
