3-3-10 Real Time Clock (Hour)
Select in the RS-232 Bi-directional settings mode
to set the real time clock for time.
MR key  move the flashing letter to left
Enter key  perform action
LCD shows the current time (24 hours)
Press Enter key
Use“0” ~ “9” keys to key
in “hour”, “minute”
and “second”.
Press Enter key
To exit the RS-232
Bi-directional settings,
key in “00” and press
Enter key.
