METALJET D2+ INSTALLATION
Revision 19, November 2016 Page 4-12
2. Connect the return hose to the fitting on the upper cooling block circled in green in Connect the water
Figure 4-12. Upper cooling block with water hoses connected and flow direction indicated blue arrows.
To lower
cooling block
