METALJET D2+ TECHNICAL DATA
Revision 19, November 2016 Page 11-1
11 TECHNICAL DATA
Parameter
Value
Electron gun/x-ray head
Max acceleration voltage & beam current
70 kV / 4.28 mA
Max electron-beam power
300 W
Min x-ray focal spot size
10 µm
Jet alloy (target material)
ExAlloy-G1/ ExAlloy-I1
Max x-ray leakage at full power
0.6 µSv/h
X-ray window material
Beryllium
Focus to object distance (FOD)
24.8 mm (with shutter), 18 mm (without shutter)
Cooling method
Water cooling
Weight (excluding cables and liquid metal loop)
~61 kg
Pump box
Mains supply
200-240 VAC, 50/60 Hz, 2 kW
200-240 V 2~, 50/60 Hz, 2 kW
Supply connector
Panel mount mains inlet for IEC 60320-C-13 cable
Fuse
T10A, 250V
Dimensions
15.3U 19” rack mounted, 48 cm deep
Weight
92 kg
X-ray system controller
Mains supply
200-240 VAC, 50/60 Hz, 0.5 kW
200-240 V 2~, 50/60 Hz, 0.5 kW
Supply connector
Panel mount mains inlet for IEC 60320-C-13 cable
Fuse
F3.15A, 250V
Dimensions
4U, 19” rack mounted, 40 cm deep
Weight
12.2 kg
X-ray high-voltage controller
Max acceleration voltage & beam current
70 kV / 4.28 mA
Mains supply
200-240 VAC, 50/60 Hz, 0.5 kW
200-240 V 2~, 50/60 Hz, 0.5 kW
Supply connector
Panel mount mains inlet for IEC 60320-C-13 cable
Fuse
F3.15A, 250V
Dimensions
4U, 19” rack mounted, 40 cm deep
Weight
12.6 kg
