METALJET D2+ INSTALLATION
Revision 19, November 2016 Page 4-28
4.6 System integration
This section gives recommendations regarding system integration and accessibility of system components to
allow maintenance and service to the MetalJet D2+ system. It also explains how to integrate the system
controller in the system IT infrastructure.
4.6.1 System accessibility
Easy access to the system simplify regular maintenance and service and should be considered during the
system design phase. Servicing the jet pump benefit from easy access to the pump box from all four sides.
However, in cases where this is not possible access from the front should be prioritized, see Figure 4-29.
Figure 4-29. Easy access to the pump box simplify regular maintenance and service to the system and should be
considered during the system design phase.
