METALJET D2+ SPARE PARTS
Revision 19, November 2016 Page 10-1
10 SPARE PARTS
Below is a list of the most common spare parts needed for maintenance of the MetalJet D2+ source. We
recommend that you stock the parts labeled with “S”, since these are standard wear parts.
Part #
Group / Part Name
Description
Cathodes
S-022-0016
A200 Cathode Assembly
The cathode is typically replaced when the source no
longer can maintain its specification. Life time of a
cathode vary depending on operating parameters.
(See section 6.3 in the manual)
S-022-0000
Kit of 4 x A200 Cathode Assemblies
S-022-0038
A100 Cathode Assembly
S-022-0001
Kit of 4 x A100 Cathode Assemblies
Nozzles
S-034-0049
Nozzle assembly
A fresh Nozzle increase the probability of a successful
start up. (See section 6.4 in the operating manual)
S-034-0000
Kit of 4 x Nozzle assemblies
Misc.
S-034-0034
Exit window
The heated exit window has intrinsically a very long
lifetime but may be damaged by other source
failures. (See section 6.5 in the operating manual)
S-023-0001
Alloy top off - 50 ml - ExAlloy G1
Alloy top off may be needed in connection with
service of the liquid-metal flow path.
S-023-0003
Alloy top off - 50 ml - ExAlloy I1
S-035-0000
Particle filter
On consecutive jet start-up failures (see section 6.4 in
the manual) this inline filter should be replaced.
Jet-Pump Parts
S-023-0000
Jet-pump check valve
One or two check valves should be replaced if the
liquid-metal pump cannot maintain correct operating
pressure.
S-023-0004
Jet-pump drive unit lubricant kit (3 x 0.5l)
The drive unit lubricant should be replaced every
year. This kit contains three bottles to last three
years.
S-023-0002
Jet-pump service kit
Diaphragm should be replaced every four years when
also the hydraulic oil and drive unit lubricant is
replaced.
Contents:
Jet-pump diaphragm
Jet-pump drive unit lubricant
Jet-pump hydraulic oil (1.7 L needed for refill)
