FATEK P5070S - Omron SYSMAC CPM Series

103
Omron SYSMAC CPM Series
2.3.5.1 Communication Setting
Item
Default Setting
Remark
Signal Level
RS232
Baud Rate
9600
Data Length
7
Stop Bit
2
Parity
Even
PLC Station No.
0
Communication Method
HOSTLINK
2.3.5.2 Memory Resource Review
Device
Description
Data bit
Min.
Max.
TNB
Timer Area
1
0
255
CNB
Counter Area
1
0
255
IR
IR area
16
0
227
HR
HR area
16
0
19
AR
AR area
16
0
23
LR
LR area
16
0
15
TN
Timer area
16
0
255
CN
Counter area
16
0
255
DM
DM area
16
0
6655
2.3.5.3 Connecting to HMI
Configuring the PLC
Use CX-Programmer to configure the port of the PLC.
Under 專案 Task 工作區 Sidebar, expand 設定.
