FATEK P5070S - EHV Series ( Ethernet )

135
EHV Series ( Ethernet )
2.5.2.1 Communication Setting
Item
Default Setting
Remark
Signal Level
Ethernet
Internet Protocol
192.168.1.100
Port
3004
PLC Station No.
0
Communication Method
h protocol ( Ethernet )
2.5.2.2 Memory Resource Review
Device
Description
Data
bit
Input
format
Min.
Max.
X
Input bit
1
DDDDD
0
65535
Y
Output bit
1
DDDDD
0
65535
M
Memory bit
1
HHHH
0
FFFF
R
Internal output bit
1
HHH
0
FFF
L
Link bit
1
HHHH
0
3FFF
TD
Timer
1
DDDD
0
2559
CU
Counter
1
DDD
0
511
WX
Input word
16
DDDD
0
9999
WY
Output word
16
DDDD
0
9999
WM
Memory word
16
HHH
0
FFF
WR
Internal output word
16
HHHH
0
FFFF
