FATEK P5070S - Hitachi; EHV Series

132
2.5 Hitachi
EHV Series
2.5.1.1 Communication Setting
Item
Default Setting
Remark
Signal Level
RS232C
Baud Rate
19200
Data Length
7
Stop Bit
1
Parity
Even
PLC Station No.
0
Communication Method
h protocol
2.5.1.2 Memory Resource Review
Device
Description
Data
bit
Input
format
Min.
Max.
X
Input bit
1
DDDDD
0
65535
Y
Output bit
1
DDDDD
0
65535
M
Memory bit
1
HHHH
0
FFFF
R
Internaloutput bit
1
HHH
0
FFF
L
Link bit
1
HHHH
0
3FFF
TD
Timer
1
DDDD
0
2559
CU
Counter
1
DDD
0
511
WX
Input word
16
DDDD
0
9999
WY
Output word
16
DDDD
0
9999
WM
Memory word
16
HHH
0
FFF
WR
Internaloutput word
16
HHHH
0
FFFF
WL
Link word
16
HHH
0
3FF
TC
Timer / Counter
16
DDDD
0
2559
2.5.1.3 Connecting to HMI
Connecting PLC to HMI
Within the Link configuration window in FvDesigner:
Under Interface Type select Serial
Under Manufacturer select Hitachi Ltd.
Under Product Series select EHV Series
Under Port select the port number that corresponds to the RS232 connection on the
