FATEK P5070S - FATEK FBs;B1;B1 z;HB1 Ethernet

17
Wiring Diagrams:P5043S/P5043N/P5070VS/P5102VS
FBs/B1/B1z/HB1 (TCP)
2.1.3.1 Communication Setting
Item
Default Setting
Remark
Signal Level
Ethernet
Internet Protocol
192.168.1.3
Port
500
PLC Station No.
0
Communication Method
TCP
2.1.3.2 Memory Resource Review
Device
Data Bits
Address
Format
Min.
Max.
Description
X
1
DDDD
0
255
Input Discrete
Y
1
DDDD
0
255
Output Relay
M
1
DDDD
0
2001
Internal Relay
S
1
DDDD
0
999
Step Relay
T
1
DDDD
0
255
Timer Discrete
C
1
DDDD
0
255
Counter Discrete
WX
16
DDDD
0
255
Input Discrete
WY
16
DDDD
0
255
Output Relay
