FATEK P5070S - FX5 U Ethernet

63
FX5U Ethernet
2.2.7.1 Communication Setting
Item
Default Setting
Remark
Signal Level
Ethernet
Internet Protocol
0.0.0.0
Port
1025
PLC Station No.
0
Communication Method
MC protocol 3E
Binary/ASCII
2.2.7.2 Memory Resource Review
Device
Description
Data
bit
Input
Format
Min.
Max.
X
Input Relay
1
OOOO
0
1777
Y
Output Relay
1
OOOO
0
1777
M
Internal Relay
1
DDDDD
0
32767
B
Link Relay
1
HHHH
0
7FFF
F
Annunciator
1
DDDDD
0
32767
SB
Link Special Relay
1
HHHH
0
7FFF
S
Step Relay
1
DDDD
0
4095
TS
Timer Contact
1
DDDD
0
1023
TC
Timer Coil
1
DDDD
0
1023
SS
Retentive Timer
Contact
1
DDDD
0
1023
SC
Retentive Timer
Coil
1
DDDD
0
1023
CS
Counter Contact
1
DDDD
0
1023
CC
Counter Coil
1
DDDD
0
1023
LCS
*1
Long Counter
Contact
1
DDDD
0
1023
LCC
*1
Long Counter Coil
1
DDDD
0
1023
SM
Special Relay
1
DDDD
0
9999
WX
*2
Input Relay
16
OOOO
0
1760
WY
*2
Output Relay
16
OOOO
0
1760
WM
*3
Internal Relay
16
DDDDD
0
32752
B_Word
*3
Link Relay
16
HHHH
0
7FF0
F_Word
*3
Annunciator
16
DDDDD
0
32752
