FATEK P5070S - Fbe (TCP)

20
Use the IP address and port number assigned on the PLC
FBe (TCP)
2.1.4.1 Communication Setting
Item
Default Setting
Remark
Signal Level
Ethernet
Internet Protocol
192.168.1.3
Port
500
PLC Station No.
0
Communication Method
TCP
2.1.4.2 Memory Resource Review
Device
Data Bits
Address
Format
Min.
Max.
Description
X
1
DDDD
0
255
Input Discrete
Y
1
DDDD
0
255
Output Relay
M
1
DDDD
0
2001
Internal Relay
S
1
DDDD
0
999
Step Relay
T
1
DDDD
0
255
Timer Discrete
C
1
DDDD
0
255
Counter Discrete
WX
16
DDDD
0
255
Input Discrete
WY
16
DDDD
0
255
Output Relay
WM
16
DDDD
0
2001
Input Relay
WS
16
DDDD
0
999
Step Relay
RT
16
DDDD
0
255
Timer Register
RC
16
DDDD
0
199
Counter Register
DRC
32
DDDD
200
255
Counter Register
R
16
DDDD
0
8071
Data Register
D
16
DDDD
0
4095
Data Register
2.1.4.3 Connecting to HMI
Configuring IP Address on PLC
Use the application FATEK Ethernet Module Configuration Tool to configure the IP
address of the PLC. Connect an Ethernet cable to the PLC. Under Attached Media,
select LAN and press scan.
