FATEK P5070S - Schneider; Modbus Rtu

136
WL
Link word
16
HHH
0
3FF
TC
Timer / Counter
16
DDDD
0
2559
2.6 Schneider
MODBUS RTU
2.6.1.1 Communication Setting
Item
Default Setting
Remark
Signal Level
RS485 2W
Baud Rate
19200
Data Length
8
Stop Bit
1
Parity
None
PLC Station No.
0
Communication Method
MODBUS RTU(Zero-based)
2.6.1.2 Memory Resource Review
Device
Description
Data bit
Input
format
Min.
Max.
%M
Memory bit
1
DDDDD
0
65535
%MW
Memory word
16
DDDDD
0
65535
2.6.1.3 Connecting to HMI
Configuring the PLC
Use TwidoSuite to configure the port of the PLC.,
expand Describe tab and creation Modbus setting,
Chick MY NETWORK and configure it to the settings detailed below.
