FATEK P5070S - Delta; DVP Series

174
2.9 Delta
DVP Series
2.9.1.1 Communication Setting
Item
Default Setting
Remark
Signal Level
RS232C
Baud Rate
9600
Data Length
7
Stop Bit
1
Parity
Even
PLC Station No.
0
Communication Method
MODBUS ASCII
2.9.1.2 Memory Resource Review
Device
Description
Data
bit
Input
format
Min.
Max.
X
Input relay
1
OOO
0
377
Y
Output relay
1
OOO
0
377
M
Auxiliary relay
1
DDDD
0
4095
S
Step
1
DDDD
0
1023
T
Timer
1
DDD
0
255
C
Counter
1
DDD
0
255
CV
Counter memory
16
DDD
0
199
TV
Timer memory
16
DDD
0
255
D
Data register
16
DDDDD
0
11999
SCV
Counter memory
32
DDD
200
255
2.9.1.3 Connecting to HMI
Configuring the PLC
Use ISPsoft to configure the port of the PLC.
But RS232 can’t change setting.
Note: For more detailed information please refer to the PLC manual.
Connecting PLC to HMI
