FATEK P5070S - Omron SYSMAC CS;CJ Series

94
Within the Link configuration window in FvDesigner:
Under Interface Type select Ethernet
Under Manufacturer select Omron Corporation
Under Product Series select Sysmac CP Series (FINS/TCP)
Enter the IP Address that was written into the PLC
Enter 9600 for the Port
Omron SYSMAC CS/CJ Series
2.3.3.1 Communication Setting
Item
Default Setting
Remark
Signal Level
RS232/RS422
Baud Rate
9600
Data Length
7
Stop Bit
2
Parity
Even
PLC Station No.
0
Communication Method
FINS
2.3.3.2 Memory Resource Review
Device
Description
Data bit
Min.
Max.
TK
Task Flag
1
0
127
TIM
Timer Area
1
0
4095
CNT
Counter Area
1
0
4095
CIO
CIO Area
16
0
6143
W
Work Area
16
0
511
H
Holding Bit Area
16
0
1535
A
Auxiliary Bit Area
16
0
11535
T
Timer Area
16
0
4095
C
Counter Area
16
0
4095
D
DM Area
16
0
32767
E0
EM Bank 0
16
0
32767
E1
EM Bank 1
16
0
32767
E2
EM Bank 2
16
0
32767
E3
EM Bank 3
16
0
32767
E4
EM Bank 4
16
0
32767
