95
E5
EM Bank 5
16
0
32767
E6
EM Bank 6
16
0
32767
E7
EM Bank 7
16
0
32767
E8
EM Bank 8
16
0
32767
E9
EM Bank 9
16
0
32767
EA
EM Bank 10
16
0
32767
EB
EM Bank 11
16
0
32767
EC
EM Bank 12
16
0
32767
EM
Current EM Bank
16
0
32767
DR
Data Register
16
0
15
IR
Index Register
32
0
15
2.3.3.3 Connecting to HMI
Configuring the PLC
Use CX-Programmer to configure the port of the PLC.
Under 專案 Task 工作區 Sidebar, expand 設定.
After navigate to Serial Prot tab and configure it to the settings detailed below.
Note: For more detailed information please refer to the PLC manual.
Connecting PLC to HMI
