FATEK P5070S - Fbs;B1;B1 Z;Hb1 (UDP)

22
Within the Link configuration window in FvDesigner:
Under Interface Type select Ethernet
Under Manufacturer select FATEK Automation Corp
Under Product Series select FATEK FBe (TCP)
Use the IP address assigned on the PLC
Leave the Port at the default value
FBs/B1/B1z/HB1 (UDP)
2.1.5.1 Communication Setting
Item
Default Settings
Remark
Signal Level
Ethernet
Internet Protocol
192.168.1.100
Port
500
PLC Station No.
0
Communication
Method
UDP
2.1.5.2 Memory Resource Review
