FATEK P5070S - Mitsubishi FX2 N Series

26
FX2N CPU
2.2.1.1 Communication Setting
Item
Default Setting
Remark
Signal Level
RS485 4W
Baud Rate
9600
Data Length
7
Stop Bit
1
Parity
Even
PLC Station No.
0
Communication Method
Programming Protocol
2.2.1.2 Memory Resource Review
Device
Description
Data bit
Min.
Max.
X
Input Discrete
1
0
377
Y
Output Relay
1
0
377
M
Internal Relay
1
0
7999
SM
Special Relay
1
8000
8255
S
Step Relay
1
0
4095
TS
Timer Discrete
1
0
255
CS
Counter Discrete
1
0
255
WX
Input Discrete
16
0
360
WY
Output Relay
16
0
360
WM
Internal Relay
16
0
7984
WS
Step Relay
16
0
4080
TN
Timer Memory
16
0
255
CN
Counter Memory
16
0
199
D
Data Register
16
0
7999
SD
Special Data Register
16
8000
8255
DCN
Counter Memory
32
200
255
2.2.1.3 Connecting to HMI
Connecting PLC to HMI
