FATEK P5070S - Micrologix Series

159
Within the Link configuration window in FvDesigner:
Under Interface Type select Ethernet
Under Manufacturer select Allen-Bradley
Under Product Series select Micrologix (Ethernet/IP)
Enter the IP Address that was written into the PLC.
Keep the Port at the default setting.
MicroLogix Series
2.7.5.1 Communication Setting
Item
Default Setting
Remark
Signal Level
RS232
Baud Rate
19200
Data Length
8
Stop Bit
1
Parity
None
PLC Station No.
1
TX Control
CRC
CRC/BCC
