Communication Method
DF1 Protocol
2.7.5.2 PLC Resource Review
Device
Description
Data bit
Input
format
Min.
Max.
O
Output File
1/16
O F:S.D
O0:0.0
O0:30.255
I
Intput File
1/16
I F:S.D
I1:0.0
I1:30.255
S
Status File
1/16
S F:E
S2:0
S2:163
B
Bit File
1/16
B F:E
B3:0
B255:255
T
Timer File
1/16
T F:E.D
T4:0.0
T255:255.2
C
Counter File
1/16
C F:E.D
C5:0.0
C255:255.2
R
Control File
1/16
R F:E.D
R6:0.0
R255:255.2
N
Integer File
1/16
N F:E
N7:0
N255:255
F
Floating File
32
F F:E
F8:0
F255:255
ST
String File
1/16
ST F:E.D
ST9:0.0
ST255:255.41
L
Long word
File
32
L F:E
L9:0
L255:255
2.7.5.3 Connecting to HMI
Configuring the PLC
To connect the PLC to a computer, follow the same steps detailed in the previous
chapter. Configuring the serial connection of the PLC is the same as configuring the IP
address of the PLC.
Double click Channel Configuration and navigate to the Channel 0 tab. Here, the serial
connection settings can be adjusted if needed.
