FATEK P5070S - Page 64

64
SB_Word
*3
Link Special Relay
16
HHHH
0
7FF0
WS
*3
Step Relay
16
DDDD
0
4080
TS_Word
*3
Timer Contact
16
DDDD
0
1008
TC_Word
*3
Timer Coil
16
DDDD
0
1008
SS_Word
*3
Retentive Timer
Contact
16
DDDD
0
1008
SC_Word
*3
Retentive Timer
Coil
16
DDDD
0
1008
CS_Word
*3
Counter Contact
16
DDDD
0
1008
CC_Word
*3
Counter Coil
16
DDDD
0
1008
SM_Word
*3
Special Relay
16
DDDD
0
9984
TN
Timer Current
Value
16
DDDD
0
1023
SN
Retentive Timer
Current Value
16
DDDD
0
1023
CN
Counter Current
Value
16
DDDD
0
1023
D
Data Register
16
DDDD
0
7999
W
Link Register
16
HHHH
0
7FFF
SW
Link special
Register
16
HHHH
0
7FFF
SD
Special Register
16
DDDDD
0
11999
R
File Register
16
DDDDD
0
32767
Z
Index Register
16
DD
0
23
LCN
*1
Long Counter
Current Value
32
DDDD
0
1023
LZ
Long Index Register
32
DD
0
11
*1
Binary mode support only
*2
Address increased by 0, 20, 40, 60…
*3
Address increased by 0, 20, 40, 60…
