108
Q
Output
1
0
31
M
Bit Memory
1
0
31
V
Variable Memory
1
0
20479
C
Counter
1
0
255
T
Timer
1
0
255
S
Sequential Control Relays
1
0
31
SM
Special Memory Bit
1
0
1535
IW
Input
16
0
31
QW
Output
16
0
31
TW
Timer
16
0
255
CW
Counter
16
0
255
MW
Word Memory
16
0
31
SW
SCR
16
0
31
VW
V Memory
16
0
20479
SMW
Special Memory
16
0
1535
AIW
Analog Input
16
0
111
AQW
Analog Output
16
0
111
2.4.1.3 Connecting to HMI
Configuring the PLC
Use Step7 microWIN smart to configure the port of the PLC.
Under the Project Sidebar, expand CPU model and configure it to the settings detailed
below.
