123
C
Counter
1
0
255
T
Timer
1
0
255
S
Sequential Control
Relays
1
0
31
SM
Special Memory Bit
1
0
549
IW
Input
16
0
14
QW
Output
16
0
14
TW
Timer
16
0
255
CW
Counter
16
0
255
MW
Word Memory
16
0
30
SW
SCR
16
0
30
VW
V Memory
16
0
10238
SMW
Special Memory
16
0
548
AIW
Analog Input
16
0
62
AQW
Analog Output
16
0
62
ID
Input
32
0
12
QD
Output
32
0
12
MD
Word Memory
32
0
28
SD
SCR
32
0
28
VD
V Memory
32
0
10236
SMD
Special Memory
32
0
546
2.4.4.3 Connecting to HMI
Configuring the PLC
Use Step7 MicroWIN SP9 to configure the port of the PLC.
After choose the PLC type, click communication in the view field, then double click the
‘’double click to refresh’’ to connect.
