182
Within the Link configuration window in FvDesigner:
Under Interface Type select Serial
Under Manufacturer select Delta Electronics, Inc
Under Product Series select Delta AH500 Series
Select the appropriate Port to establish connection with the PLC.
Verify the other parameters are configured correctly.
2.9.2.4 Wiring Diagrams
HMI COM1 Pinout
