FATEK P5070S - Page 211

211
T
Timer
1
DDDD
0
511
C
Counter
1
DDDD
0
255
CTC_sts
High-speed counter
comparator
(contact)
1
D
0
7
CR
Control relay
1
DDdd
0
8915
VB
Work relay
1
HHHH
0
1FFF
DM
Data memory
16
DDDDD
0
32767
W
Link register
16
HHHH
0
3FFF
TM
Temporary data
memory
16
DDD
0
511
CM
Control memory
16
DDDD
0
8999
VM
Work memory
16
DDDDD
0
9999
Z
Index register
32
D
1
12
TC
Timer (current
value)
32
DDDD
0
511
TS
Timer (set value)
32
DDDD
0
511
CC
Counter (current
value)
32
DDDD
0
255
CS
Counter (set value)
32
DDDD
0
255
CTH
High-speed counter
(current value)
32
D
0
3
CTC
High-speed counter
comparator (set
value)
32
D
0
7
2.12.3.3 Connecting to HMI
Configuring the PLC
Use the software KV Studio (ver. 9.02) to configure the PLC.
Right click the device in Unit configuration and select Unit Editor.
