FATEK P5070S - Page 5

5
1
TX+
DATA+
2
RX
3
TX
4
RX+
5
GND
GND
GND
GND
6
TX-
DATA-
7
DATA+
8
DATA-
9
RX-
P5070S/ P5070N/ P5070N1/ P5102S/ P5102N/ P5102N1
Serial Interface
COM1(RS-232[TXD,RXD,RTS,CTS]),
COM3(RS-422/485), COM4(RS-485)
Serial Layout
RS-232
PIN#
COM1
1
2
RX
3
TX
4
5
GND
6
7
RTS
8
CTS
9
RS-422/
485
Old Model
PIN#
COM3
(RS-422)
COM3
(RS-485)
COM4
