56
SC_Word
*3
Retentive Timer
Coil
16
DDDD
0
1008
CS_Word
*3
Counter Contact
16
DDDD
0
1008
CC_Word
*3
Counter Coil
16
DDDD
0
1008
SM_Word
*3
Special Relay
16
DDDD
0
9984
TN
Timer Current
Value
16
DDDD
0
1023
SN
Retentive Timer
Current Value
16
DDDD
0
1023
CN
Counter Current
Value
16
DDDD
0
1023
D
Data Register
16
DDDD
0
7999
W
Link Register
16
HHHH
0
7FFF
SW
Link special
Register
16
HHHH
0
7FFF
SD
Special Register
16
DDDDD
0
11999
R
File Register
16
DDDDD
0
32767
Z
Index Register
16
DD
0
23
LCN
*1
Long Counter
Current Value
32
DDDD
0
1023
LZ
Long Index
Register
32
DD
0
11
*1
Binary mode support only
*2
Address increased by 0, 20, 40, 60…
*3
Address increased by 0, 20, 40, 60…
2.2.6.3 Connecting to HMI
Configuring the PLC
Connect the PLC using an Ethernet cable. The following setup uses an Ethernet Port
Direct Connection to configure the PLC.
Use MELSOFT GX Works3 to configure the port of the PLC.
Under the Online menu option, select Read from PLC.
Select the FX5CPU option for the Series.
