71
TC_Word
Timer Coil
16
DDDD
0
32752
SS_Word
Retentive Timer
Contact
16
DDDD
0
32752
SC_Word
Retentive Timer Coil
16
DDDD
0
32752
CS_Word
Counter Contact
16
DDDD
0
32752
CC_Word
Counter Coil
16
DDDD
0
32752
SM_Word
Special Relay
16
DDDD
0
2032
TN
Timer Current Value
16
DDDD
0
32752
SN
Retentive Timer
Current Value
16
DDDD
0
32752
CN
Counter Current
Value
16
DDDD
0
32752
D
Data Register
16
DDDDD
0
39935
W
Link Register
16
HHHH
0
9bff
SW
Link special Register
16
HHH
0
7FFF
SD
Special Register
16
DDDD
0
2047
R
File Register
16
DDDDD
0
32767
Z
Index Register
16
DD
0
19
ZR
File Register
16
HHHHH
0
9fff
2.2.8.3 Connecting to HMI
Configuring the PLC
Use MELSOFT GX Works2 to configure the port of the QJ71C24N Module.
Under the Project Sidebar, expand Intelligent Function Module and select Switch
Setting.
