Fazzini FM5000C - Rightview; Leftview; Rearview

2-3
FM5000C - FM5000PLUS
Maternal/Fetal Monitor
User Manual
2.4.2 RightView
Display screen
Sensor
sockets
Figure 2-2 Left v i ew
2.4.3 LeftView
Display screen
Recor d er
Figure 2-3 Left v i ew
2.4.4 RearView
Network c onn ect or
USB connecto r
AC power supply
scoket
Handle
Equipotential
terminal
Figure2-4Rear view
Warning
 The network connector is designed for Our company central monitoring system only.
 Only the analog or digital equipments complying with the specified IEC standards (like IEC
60950 for data processing equipments, IEC 60601-1 for medical equipments, etc.) are allowed
