FM5000C - FM5000PLUS
Maternal/Fetal Monitor
Chapter 7 User Screens
7.1 Overview
The monitor provides several screens for the user to select, including fetal monitoring screen, mother/fetus
monitoring screen, mother monitoring screen, list screen, trend screen, oxyCRG screen and big font screen.
User can get different screen messages from different screens.
7.1.1 Fetal Monitoring Screen
You can see the FHR value, FHR trace, TOCO value, TOCO waveform, manual/auto FM mark and auto
FM waveform on the fetal monitoring screen.
To open the fetal monitoring screen:
(a) Click [SCREENS] on-screen key;
(b) Or access [MAIN MENU] and select [SCREENS]
(c) Select [FETAL SCREEN] to open the fetal monitoring screen, as shown below:
Figure 7-1Fetalmonitoring screen
