FM5000C - FM5000PLUS
Maternal/Fetal Monitor
7.3 Tailoring Your Screens
You can tailor your monitor’s screen by setting:
Waveform sweep speed;
Waveform display style;
Parameter and waveform display color;
Waveform exchange;
Gain.
7.3.1 Changing the Waveform Sweep Speed
1. Select fetal monitoring waveform, for example FHR waveform, and the menu [FHR SETUP] will be
displayed. Select [SWEEP] and choose the sweep speed for FHR waveform from [1 CM/MIN], [2
CM/MIN] and [3 CM/MIN].
2. Select mother monitoring waveform, for example ECG waveform, and the menu [ECG WAVE] will be
displayed. Select [SWEEP] and choose the sweep speed for ECG waveform from [6.25mm/s],
[12.5mm/s], [25.0mm/s] and [50.0mm/s].
7.3.2 Setting the DisplayColor
1. Select fetal monitoring waveform, for example FHR1 waveform, and the menu [FHR SETUP] will be
displayed. Select [FHR1 DISP COLOR] and choose the display color for FHR1 waveform from
[GREEN], [CYAN], [RED],[YELLOW], [WHITE], [BLUE] and [PURPLE];
2. Select mother monitoring waveform, for example ECG waveform, and the menu [ECG WAVE] will be
displayed. Select [WAVE COLOR] and choose the display color for ECG waveform from [GREEN],
[CYAN], [RED],[YELLOW], [WHITE], [BLUE] and [PURPLE].
7.3.3 Setting the Waveform Display Style
This operation is not available for fetal monitoring waveforms.
1. Select mother monitoring waveform, for example ECG waveform, and the menu [ECG WAVE] will be
displayed.
2. Select [WAVE TYPE] and choose the waveform display style from [LINE], [COLOR]and[BOLD]
7.3.4 Waveform Exchange
This operation is not available for fetal monitoring waveforms.
1. Select mother monitoring waveform, for example ECG waveform, and the menu [ECG WAVE] will be
displayed.
2. Select [WAVE EXCHANGE] and select the waveform to be exchanged.
