14
OPERATION
1. Driver seat
WARNING:
Never adjust the seat while the tractor is moving (risk of accident).
If a seat belt is available, always attach it.
1.1 Super deluxe seat
Operation_Pic_number:1
Text-module
A = Automatic weight and height adjust-
ment.
B = Swivel mechanism.
C = Longitudinal adjustment.
D = Backrest adjustment.
E = Lumbar support (curvature), pneumatic
operation.
F = Seat bolster (depth adjustment).
G = Seat bolster (tilt adjustment).
H = Horizontal springing (on/off).
I = Vertical springing (adjustable from soft to
hard in four levels).
J = Backrest extension.
K = Behind the moulding:
Seat belt fixing point.
L = Seat heating.
Fig.1
