117
OPERATION
Text-module
NOTE:
Press ESC to return to previous menu level.
28. Storing the settings
Text-module
This setting saving function allows four different
sets of parameters to be saved and named un-
der any name and recalled when needed.
28.1 Setting that can be saved
Text-module
Comfort front power lift
Lock status
Cross adjustment - floating setting
Lift flow regulation
Lower flow regulation
Maximum lifting height
Text-module
Rear power lift (EPC)
Lock status
Slip control status
Lowering speed
Mix ratio (position/traction control)
Wheel slip setting
Switch-on speed for vibration damping
Maximum lifting height
Automatic function
Text-module
Rear PTO
Rear PTO rpm
Automatic function
Text-module
Electrical valves 1-4
Valve priority
Lock status
Kick-out status
Activate PTO measurement (can also be
combined with lifting gear measurement
and/or external counter).
To activate, press key (F4) - the
green symbol indicates active
status.
Measuring and counting only
available with rear or front PTO
engaged.
Activating external counter input.
Connect cable (ID. No. 0071 023
100) to blue socket (see picture
OPERATION Fig. 270).
To activate, press key (F5). When
activated, the symbol is lit green.
Measuring and counting only
possible if there is a sealed
counting sensor on the implement
(e.g. hydraulic fertiliser spreader)
and this is connected to the
on-board computer.
Timer setting
Lift flow regulation
Lower flow regulation
Timer function selection
Text-module
External valve actuation
Valve selection (3rd valve or 4th valve)
Text-module
Load limit control
Engine speed drop set value
Text-module
Cruise control
Tempomat cruise control speed 1
Tempomat cruise control speed
pre-selection 1
Speed cruise control 2
Tempomat cruise control speed
pre-selection 2
Text-module
Quick reverse
Reversing speed
Text-module
Electronic accelerator
Min/Max engine speed values
Text-module
4WD
4-WD pre-selection
Text-module
Differential lock
Pre-select differential lock
Text-module
Suspension
Suspension mode pre-selection
Text-module
Tractor Management System (TMS)
TMS operation ON
Accelerator mode ON
Set engine speed range
Operating status (PTO, power lift, hydraulic
valve function) of the engine speed control
Text-module
Variotronic Ti
Stored operating sequences available for
play back
