TECHNICAL DATA
Maintenance Schedule
FENDT 916 Vario, 920 Vario, 924 Vario, 926 Vario, 930 Vario
Vehicle Nos. 916 .. 7001, 920 .. 7001, 924 .. 7001, 926 .. 7001, 930 .. 2001
Maintenance jobs during and after the running-in period and for the workshop after the 5th Service
No.
Services
regularly 1)
daily
Job Schedule
See also Operating Manual
Care and Maintenance
General notes and technical data, types of fluid and oil
Correct levels are determined by dipstick check or from the overflow at the
inspection hole.
Observe all accident prevention regulations and comply with directives for
handling and disposing of fluid and lubricants.
1.
50
2.
250
3.
500
4.
750
5.
1000
annu
al or
every
500
every 2
years
or
2000
operating hours
1 Engine
X Check oil level. The difference between the MIN and MAX marking on the dipstick is approx.
4.0 litres.
After 100 operating hours add oil to the MAX mark of the dipstick.
Wait until level is just above the MIN marking. Do not fill above MAX marking.
X X X X Replace engine oil and filter cartridge 2). Oil quantity: 24.0 litres
Oil grade: Fendt Extra Grade 15W-40 SHPD, Fendt Ultra Grade
10W-40 UHPD or SHPD engine oils acc. to ACEA E3-96.
X 1000 Check valve clearance, adjust if necessary (at
workshop).
Valve clearance: Intake valve 0.5 mm, exhaust valve 0.5 mm, with engine
cold (max 50
°C).
X X as re-
quired
Clean the filter strainer and filter chamber in the
fuel hand pump.
Repeat more often if engine output begins to fall.
X annu-
ally
Replace fuel filter unit. Repeat more often if engine output begins to fall.
as re-
quired
Replace preliminary fuel filter (optional). Repeat more often if engine output begins to fall.
X X X X Check V-belt, retighten if necessary 1). Air conditioner
compressor:
400+50 N (40+5 kp).
Alternator left side. 450+50 N (45+5 kp).
X X V-belt tightener. Adjust to distance of 92 mm between centres.
X X X X X Check coolant level, top up if necessary. Coolant level: With the engine cold, top up if necessary with clean, lime-
free water containing antifreeze to between the MIN and
MAX mark on the expansion reservoir.
X Replace coolant. Coolant quantity: 26.0 litres
A concentration of 35 - 50% vol. of antifreeze and anticorrosion agent is neces-
sary throughout the year, even in frost-free areas.
Add anti-freeze as indicated in Fendt Customer Service memo 11/02.
