FENDT 926 Vario User Manual

247
TECHNICAL DATA
1. Technical data
Text-module
Model 916 920
Engine
Engine type DO836LE508 DO836LE507
Turbocharger / intercooler with / with with / with
No. of cylinders / cooling 6 / water 6 / water
Bore / stroke mm 108 / 125 108 / 125
Effective displacement l 6,870 6,870
Idling speed rpm 730 ±30 730 ±30
Rated speed rpm 2150 2150
Engine speed without load rpm 2450-2500 2450-2500
Fuel l 530 530
Engine switch-off electrical electrical
Noise level at driver's ear dB(A) 72 72
Engine alignment
Ensure vehicle stability
Lengthwise in travel direction high / low degree 25 25
Across travel direction left / right degree 25 25
Dimensions and weights
with the following tyres and track width
Tyres front 480/70 R34 480/70 R34
Tyres rear 580/70R42 580/70R42
Track width front mm 2000 2000
Track width, rear mm 1970 1970
Overall length mm 4940 4940
Overall width mm 2550 2550
Total height mm 3095 3095
Ground clearance mm 605 605
Wheelbase mm 2840 2840
Flange size front mm 1892 1892
Flange size rear mm 1890 1890
Min. track circle radius without / with steering clutch brake mm 5,9/5,4 5,9/5,4
Unloaded weight kg 8750 8750
Max. permissible gross weight 50 km/h kg 12000 12000
Max. permissible gross weight with implement, depending on
tyres kg 14000 14000
Max. permissible front axle load kg 6450 6450
Max. permissible rear axle load kg 8500 8500
Max. vertical bearing load on trailer hitch kg 2000 2000
Permissible vertical bearing load on trailer hitch kg 3000 3000
Rear PTOs 540/540E/1000
PTO shaft profile 1 3/4 6-part 1 3/4 6-part
PTO speed at rated engine speed and 540 setting rpm 596 596
PTO speed at rated engine speed and 540E setting rpm 760 760
PTO speed at rated speed and 1000 setting rpm 1108 1108
PTO speed at rated engine speed in setting 750 Nm 3500 3500
Max. permissible torque for 540E setting Nm 2100 2100
PTO speed when rated engine speed is selected for 1000 Nm 1600 1600
Front PTO 1000
PTO speed at nominal speed 1000 version rpm 1111 1111
PTO speed when rated engine speed is selected for 1000 Nm 830 830
Hydraulics
Working pressure bar 200 200
Hydraulic pump l 112 112
Hydr. oil extraction flow at max. capacity l 65 65

FENDT 926 Vario Specifications

General

Engine Power	260 hp
Transmission	Vario continuously variable transmission
Fuel Tank Capacity	500 liters
Weight	10, 500 kg
Engine type	6-cylinder turbocharged
Rated engine speed	2100 rpm
Displacement	7.5 liters
Number of cylinders	6
Maximum speed	50 km/h
Tire Options	Multiple options available
