End plates
A left-hand and a right-hand plate are required
as mechanical termination of the modular termi-
nal.
These end plates fulfil the following functions:
• They comply with protection class IP 65.
• They contain connections/contacts for the
earth cable.
• They contain holes for fitting onto walls and
onto the hat rail clamping unit.
By means of screw connectors and pre-fitted
earthing bars, the right-hand end plate of the
ISO terminal is connected conductively to the
manifold sub-bases. It is therefore sufficiently
earthed.
There are various designs of right-hand end
plate for the terminls of type 03 (MIDI/MAXI).
Each design is already fitted with an earth cable.
CAUTION
Earth the right-hand end plate with the earth
cable before fitting the terminal type 03. You
thereby avoid faults caused by electromag-
netic influences.
VIFB6 - 03/05 2. Fitting
2-6
9809c
