The following components of valve terminal
type 05 are supplied separately with + 24 V DC
via this connection:
The operating voltage for the internal elec-
tronic components and the inputs of the input
modules (pin 1: DC + 24 V, tolerance ± 25 %,
external fuse max. 3.15 A recommended).
The operating voltage for the valve outputs
and the ouputs of the output modules (pin 2:
DC + 24 V, tolerance ± 10 %, external fuse
max. 10 A slow-blowing required).
PLEASE NOTE
Check your EMERGENCY STOP circuitry, to
see which measures are required in order to
place your machine/system in a safe state in
the event of an EMERGENCY STOP (e.g.
switching off the power supply to the valves
and output modules, switching off the com-
pressed air supply).
VIFB6 - 03/05 3. Installation
3-32
9809c
